Blue Sea 5175 MRBF Terminal Fuse – 30A
SKU: 003229
In Stock
30A ignition-protected fuse with clear blown-fuse window and color-coded amperage. Meets ABYC standards for large battery banks. Requires Terminal Fuse Blocks PN 5191 or 2151. Rated up to 58V DC.
£11.49
ex VAT £9.58
-
Description
- Requires the use of Terminal Fuse Blocks PN 5191 or PN 2151—do not mount the fuse directly to the battery terminal
- Interrupt rating satisfies ABYC requirements for DC Main circuit protection on large battery banks
- Ignition protected—safe for installation aboard gasoline powered boats
- Clear window—visual indication of blown condition
- Colour coded for each amperage
Specifications Amperage 30A Ignition Protected Yes Maximum Voltage 58V DC Interrupt Capacity 10000A @ 14V DC
5000A @ 32V DC
2000A @ 58V DCWeight 0.06lb (0.03 kg) -
