Blue Sea 5190 MRBF Terminal Fuse – 300A

Name: Blue Sea 5190 MRBF Terminal Fuse - 300A
SKU: 003241
Availability: BackOrder

SKU: 003241

Available on backorder

300A ignition-protected fuse with clear window for blown condition visibility. Meets ABYC standards, ideal for large battery banks. Requires Terminal Fuse Blocks (PN 5191 or 2151). Colour-coded by amperage, rated up to 58V DC.

£14.49
ex VAT £12.08

Description
Requires the use of Terminal Fuse Blocks PN 5191 or PN 2151—do not mount the fuse directly to the battery terminal
Interrupt rating satisfies ABYC requirements for DC Main circuit protection on large battery banks
Ignition protected—safe for installation aboard gasoline powered boats
Clear window—visual indication of blown condition
Colour coded for each amperage
Amperage 300A
Ignition Protected Yes
Maximum Voltage 58V DC
Interrupt Capacity 10000A @ 14V DC
5000A @ 32V DC
2000A @ 58V DC
Weight 0.06lb (0.03 kg)
Additional information
Additional information
Brand
Blue Sea Systems
