Scanstrut TILE USB-A / USB-C Interior Charging Socket 12/24V – Black Bezel

Name: Scanstrut TILE USB-A / USB-C Interior Charging Socket 12/24V - Black Bezel
SKU: 003494
Availability: InStock

SKU: 003494

In Stock

The Scanstrut TILE Series offers sleek, high-performance USB charging designed specifically for marine or vehicle interiors. These chargers blend seamlessly into luxury environments and are an ideal way to modernise your boat, campervan, motorhome, or caravan interior. The USB-C port can provide 36W on a 12V system or 60W on a 24V system, making the SC-TILE-10 with black bezel perfect for charging modern laptops and large tablets, phones, and any other USB-A & USB-C powered devices onboard.

Featuring a compact 40mm footprint and requiring just a 29mm hole saw for easy installation, the TILE Series combines functionality and style, offering a practical but sophisticated solution for charging your everyday devices. The TILE has been deliberately designed without illumination to avoid unwanted night time light.

£44.99
ex VAT £37.49

Description
The Scanstrut TILE Series offers sleek, high-performance USB charging designed specifically for marine or vehicle interiors. These chargers blend seamlessly into luxury environments and are an ideal way to modernise your boat, campervan, motorhome, or caravan interior. The USB-C port can provide 36W on a 12V system or 60W on a 24V system, making the SC-TILE-10 with black bezel perfect for charging modern laptops and large tablets, phones, and any other USB-A & USB-C powered devices onboard.
Featuring a compact 40mm footprint and requiring just a 29mm hole saw for easy installation, the TILE Series combines functionality and style, offering a practical but sophisticated solution for charging your everyday devices. The TILE has been deliberately designed without illumination to avoid unwanted night time light.
Features
Works with 12V or 24V systems
USB-A and USB-C ports
Fast charge 2 devices simultaneously
High power – 36W (12V system) & 60W (24V system)
Non-illuminated (no distracting light at night)
Ultra-low profile, matt black plastic bezel
Easy, front-fit installation
Conformal coated electronics protect against moisture
Standard 29mm panel hole fitment
Modernise your boat or vehicle interior
Further information
To maximise charge performance, use the cable supplied with your tablet, phone etc. (e.g. USB-C to USB-C, or USB-C to Apple lightning). Devices charge at the same speed on either a 12 or 24V system, but a 24V system must be used to get the full 60W output suitable for laptops.
Fitted with 1mm² cable tails – 10A fuse recommended.
TILE USB products are designed for interior use only. Do not install in locations where water exposure is possible, as this may lead to product failure.
Input voltage: 10-30V DC (12/24V systems)
Input current: 6A max. (10A fuse recommended)
USB-A output @ 12V: 5V-3A, 9V-3A, 12V-3A max.
USB-A output @ 24V: 5V-3A, 9V-3A, 12V-3A max.
USB-C output @ 12V: 5V-3A, 9V-3A, 12V-3A max.
USB-C output @ 24V: 5V-3A, 9V-3A, 12V-3A, 15V-3A, 20V-3A max.
USB-C max. power: 36W on a 12V system, 60W on a 24V system
Charging protocols: QC3 (USB-A), PD4 QC3 (USB-C)
Standby power consumption: <0.1W
Connection: 1mm² (18AWG) flying leads, 150mm long
Panel hole required: 29mm
Overall dimensions: 66.5 (L) x 43 (W) x 43 (H) mm
Dimensions of visible facia when mounted: 43 (W) x 43 (H) x 6.2mm (D)
Min. depth required behind mounting surface: 65mm (approx.)
Min. thickness of mounting surface: 3mm
Certification: CE, FCC, UKCA, C-Tick, ROHS, WEE, UN ECE R10
Part Number : SC-TILE-10
