Blue Sea 5185 MRBF Terminal Fuse – 150A

SKU: 003236

Available on backorder

Requires the use of Terminal Fuse Blocks PN 5191 or PN 2151—do not mount the fuse directly to the battery terminal

£11.49
ex VAT £9.58

Description
- Requires the use of Terminal Fuse Blocks PN 5191 or PN 2151—do not mount the fuse directly to the battery terminal
- Interrupt rating satisfies ABYC requirements for DC Main circuit protection on large battery banks
- Ignition protected—safe for installation aboard gasoline powered boats
- Clear window—visual indication of blown condition
- Colour coded for each amperage
Specifications
Amperage 150A
Ignition Protected Yes
Maximum Voltage 58V DC
Interrupt Capacity 10000A @ 14V DC
5000A @ 32V DC
2000A @ 58V DC
Weight 0.06lb (0.03 kg)
