Blue Sea 5189 MRBF Terminal Fuse – 250A
SKU: 003240
In Stock
250A ignition-protected fuse with clear blown-fuse indicator and color-coded amperage. Meets ABYC standards, ideal for large battery banks. Requires Terminal Fuse Blocks PN 5191 or 2151. Rated up to 58V DC.
£14.49
ex VAT £12.08
-
Description
- Requires the use of Terminal Fuse Blocks PN 5191 or PN 2151—do not mount the fuse directly to the battery terminal
- Interrupt rating satisfies ABYC requirements for DC Main circuit protection on large battery banks
- Ignition protected—safe for installation aboard gasoline powered boats
- Clear window—visual indication of blown condition
- Colour coded for each amperage
Specifications Amperage 250A Ignition Protected Yes Maximum Voltage 58V DC Interrupt Capacity 10000A @ 14V DC
5000A @ 32V DC
2000A @ 58V DCWeight 0.06lb (0.03 kg) -
Additional information
Additional information
Brand
